HiBy RS8 DAP
The RS8 employs HiBy's second-generation Darwin R2R architecture, featuring a discrete resistor ladder DAC with 92 resistors per channel and 0.005% precision resistance. This design supports native 1-bit PCM decoding and offers advanced features such as adjustable FIR filters, switchable oversampling/non-oversampling modes, and DSD bypass. The device supports PCM up to 1536kHz and DSD up to DSD1024, along with full MQA 16x unfolding.
Amplification is handled by a dual operational Class A and Class AB mode, utilizing two dedicated OP1652 professional-grade op-amps and eight NXP dual bipolar transistors. This configuration aims to reduce distortion and enhance clarity and power in the sound output.
Encased in a monocoque pure titanium chassis, the RS8 combines durability with elegance. The device measures 143 x 82 x 22 mm and weighs approximately 584g, making it a substantial yet portable option for high-fidelity audio on the go. The 5.5" Full HD IPS touchscreen provides a responsive and intuitive user interface.
Specs:
Operating System: Android 12 with Google Play Store support
Processor: Qualcomm Snapdragon 665
RAM: 8GB
Internal Storage: 256GB
Expandable Storage: Up to 2TB via microSD card
Display: 5.5" Full HD IPS touchscreen (1920 x 1080 resolution, 400 ppi)
Audio DAC: Second-generation Darwin R2R architecture with 92 resistors per channel and 0.005% precision resistance
Connectivity: Bluetooth 5.0, Dual-band Wi-Fi (2.4GHz & 5GHz), USB 3.1
Ports: 3.5mm single-ended and 4.4mm balanced headphone outputs, USB-C for charging and data transfer
Battery: 12,000mAh lithium-polymer, offering up to 19 hours of playback
Dimensions: 143 x 82 x 22 mm
Weight: Approximately 584g
Chassis: Monocoque pure titanium, crafted through 17 advanced processes over 19 hours of labor
